ADVANTAGES OF SMART MICROINVERTER:
1 | Unique circuit design, choice of import industrial electronic components, higher efficiency, more stable performance. |
2 | Creative MPPT technology, efficiency more than 99%, faster and more sensitive reaction, more reliable. |
3 | Parallel type design for DC input and modularization design for inverter, small volume, distributed installation, easy for system configuration, flexible for combination, strong expansibility of system. |
4 | Adopting high-frequency isolation transformer type, high efficiency, and high security. |
5 | Perfect electrical protection function. |
6 | Aluminum alloy housing, not rust, heat-resisting, and cold-resistant as well as anti-corrosion. |
7 | Getting electronic circuit design, appearance design, and other core technology patents. |
SMART MICROINVERTER TECHNICAL PARAMETERS
Brand | IDEALPLUSING | |
Model | IPS-GT600-124 | IPS-GT600-224 |
Power | 600W | |
Solar panels | ≥600W | |
DC input range | 11~32VDC | |
MPPT Voltage | 15~22VDC | |
DC MAX current | 38A | |
AC MAX output | 650W | |
AC output range | 120VAC(90-140VAC) | 220V (190-260VAC) |
Frequency range | 50Hz/60Hz(Auto control) | |
Power Factor | >98% | |
THD | <5% | |
Phase Shift | <2% | |
Efficiency | 110VAC(90-140VAC) Version | |
Peak Efficiency | >86% | |
Stable Efficiency | >85% | |
Efficiency | 230VAC(190-260VAC) Version | |
Peak Efficiency | >87% | |
Stable Efficiency | >86% | |
Protection | Islanding Protection | |
Short-circuit Protection | ||
Converse Connection | ||
Low Voltage Protection | ||
Over Voltage Protection | ||
Over temperature Protection | ||
Work Temperature | -25℃-+65℃ | |
Work Humidity | 0%~90%RH non-condensing | |
Grade of Waterproof | Indoor design | |
Show | LED | |
Cooling | Fan | |
Stand-by Power | ＜1W | |
Mchine size | 210*165*53(MM) | |
Package size | 420*315*355(MM) | |
Mchine net weight | 1.5KG | |
Mchine gross weight | 2.2KG | |
EMC | EN61000-6-3:2007 EN61000-6-1:2007 | |
Grid Disturbance | EN 50178+EN 62109-1+VDE0126-1-12 | |
Grid Detection | DIN VDE 1026 UL1741 | |
Customize | Support | |
OEM | Support | |
Remark | This grid-tie inverter cannot be used as off grid/stand alone solar system. The output need to be connected to the grid power. Can not supply power directly to the AC loads. DO NOT use solar controller load ports to connect to the inverter. | |
