SMART MICROINVERTER INTRODUCTION:
1 | A smart grid-tie inverter is a compact unit, which directly converts direct current into alternating current for powering appliances and/or office equipment and connecting to the utility grid. |
2 | The AC output from Smart Microinverter is synchronized and in phase with the utility grid. |
3 | It is a key device of power generation systems such as PV power generation systems, wind turbine power generation systems. |
4 | Smart Microinverter specially optimized design to work with modularization of DC power supplies which includes the mainstream solar modules, 18V (36 cells) monocrystal and/or Polycrystalline solar panels, wind turbines, and batteries. |
5 | Smart Microinverters are stabilization, reliable, and high conversion efficiency items. |
6 | It is the best choice for PV power generation systems. |
SMART MICROINVERTER TECHNICAL PARAMETERS
Brand | IDEALPLUSING | ||||
Model | IPS-GTI1000-124 | IPS-GTI1000-224 | IPS-GTI1000-136 | IPS-GTI1000-236 | |
Rated Power | 1000Watt | ||||
Solar Panels | 36cells-Vmp:18-21V:Voc:20-24V | 60cells-Vmp:26-30V:Voc:34-38V 72cells-Vmp:35-39V:Voc:42-46V | |||
DC Input Range | 10.8-30VDC | 20-45VDC | |||
MPPT Voltage | 15-22VDC | 24-38VDC | |||
DC MAX. Current | 70A | 45A | |||
AC Output | 120VAC(90-140VAC) 230VAC(190-260VAC) | ||||
Frequency | 50Hz/60Hz(Auto control) | ||||
Power Factor | >98% | ||||
THD | <5% | ||||
Phase Shift | <2% | ||||
Efficiency | 120VAC(90-140VAC) Version | ||||
Peak Efficiency | 85 | 88 | |||
Stable Efficiency | 83 | 86 | |||
Efficiency | 230VAC(190-260VAC) Version | ||||
Peak Efficiency | 88 | 88 | |||
Stable Efficiency | 83 | 86 | |||
Protection | Islanding; Short-circuit; Low Voltage; Over Voltage; Over temperature Protection | ||||
Working Temperature | ‘-20℃-65℃ | ||||
Working Humidity | 0%~90%RH non-condensing | ||||
Waterproof | Indoor design | ||||
Show | Luminous Diode(LED) | ||||
Cooling | Fan | ||||
Stand-by Power | ＜1W | ||||
EMC | EN61000-6-3:2007 EN61000-6-1:2007 | ||||
Grid Disturbance | EN 50178+EN 62109-1+VDE0126-1-12 | ||||
Grid Detection | DIN VDE 1026 UL1741 | ||||
