High-voltage power supply is a general term for many members of the power supply family. It belongs to special power supply and is widely used. So how to choose the product you need? This article will answer you.
Determine the maximum output voltage
All products of high-voltage power supply are continuously adjustable from the lowest voltage to the highest output voltage. Just confirm the highest voltage of the high-voltage power supply required. If 40KV is actually used, it is recommended to choose 45KV. There is no need to choose too high a voltage.
Determine the maximum output current
There is no need to leave too much margin for the current, but the use requirements need to be determined when ordering. For example, complex working conditions such as electrospinning, withstand voltage test, capacitor charging and discharging require special protection for high-voltage power supply. Simply relying on increasing current and power increases costs, but it does not necessarily complete the work well.
Determine the maximum output power
Power = voltage X current, but for some special high-voltage power supplies, such as X-ray tube high-voltage power supplies, power, voltage, and current can be proposed as needed. Without exceeding the power requirements, there can be multiple combinations of voltage and current.
Volume
Choose a high-voltage power supply of appropriate volume according to your needs. Under the same voltage, current and power, the smaller the volume, the more expensive the price.
Stability
Choose the appropriate stability according to your needs. Under the same voltage, current and power, the higher the stability, the more expensive the price.
Temperature drift
The change of output voltage for every 1 degree Celsius change in the temperature of the high-voltage power supply. Under the same voltage, current and power, the smaller the temperature drift, the more expensive the high-voltage power supply.
Ripple
Ripple is the sum of the switching noise and AC ripple of the high-voltage power supply. According to your needs, choose the appropriate ripple requirements. Under the same voltage, current and power, the smaller the ripple, the more expensive the price.
High-voltage cable
Choose the appropriate high-voltage cable according to your needs. For example, flexible high-voltage cable, ordinary high-voltage cable, etc.
If there are other special needs, IDEALPLUSING will make it according to your needs. The above is the selection method of high-voltage power supply products, I hope it can help you.
