A switch-mode power supply (SMPS), also known as a switching converter or switching power supply, is a high-frequency power conversion device and a type of power supply. Its function is to convert a voltage at a certain level into the voltage or current required by the user through different structural forms. The input of a switching power supply is mostly AC power (such as mains power) or DC power, while the output is mostly devices that require DC power, such as personal computers. The switching power supply performs the voltage and current conversion between these two sources.
Characteristics of Switching Power Supplies
1. Small size and light weight: Because there is no power frequency transformer, the size and weight are only 20-30% of that of a linear power supply.
2. Low power consumption and high efficiency: The power transistors operate in a switching state, so the power consumption on the transistors is low, and the conversion efficiency is high, typically 60-70%, while linear power supplies only have 30-40%.
3. Simple structure and high reliability: Easy to maintain, and the current ripple rate can be easily kept relatively low.
The advantages of switching power supplies are quick and convenient power switching and effective energy saving. The disadvantages are a shorter lifespan and susceptibility to environmental factors such as humidity and temperature.
Selection Considerations for Switching Power Supplies
1. Choose the appropriate input voltage specification.
2. Choose the correct power supply: To extend the power supply's lifespan, choose a model with 30% higher rated output power.
3. Consider load characteristics: If the load is a motor, light bulb, or capacitive load, a suitable power supply should be selected to avoid overload when the current is high during operation. If the load is a motor, voltage recovery should be considered when the motor is stopped.
4. Consider the operating temperature of the power supply and whether there is additional auxiliary cooling equipment. Power supplies operating in high ambient temperatures need to have their output reduced. Refer to the derating curve of output power based on ambient temperature.
5. Select each function according to application requirements.
6. Select the required safety regulations and electromagnetic compatibility (EMC) certifications.
Switching power supplies have a wide range of applications, including household appliances, computers, electronic equipment, and automotive electronic systems.
